Dell Optiplex 7010

  1. Processor: Up to 2-core Intel Celeron G540, 2.50 GHz, 2 MB Cache, or up to 2-core Intel Core i3-3240, 3.40 GHz, 3 MB Cache, or up to 4-core Intel Core i7-3770, 3.40 GHz, 8 MB Cache
  2. Memory: 2 GB, 4 Gb, 6 GB, 8 GB, or 16 GB 1600 MHz DDR3, 2 / 4 DIMM Slots
  3. Storage: Up to 500 GB 2.5″ SATA 7200 RPM HDD, or up to 1 TB 3.5″ SATA 7200 HDD
  4. Graphics: Integrated HD Graphics, or Intel HD Graphics 2500, or Intel HD Graphics 4000, or AMD RADEON HD 7570, 1 GB, or AMD RADEON HD 7470, 1 GB
Release Date

2012

Dimensions (W x D x H)

Mini-Tower (175 x 417 x 360 mm) / Desktop (102 x 410 x 360 mm) / Small Form Factor (92.6 x 312 x 290 mm) / Ultra Small Form Factor (65 x 240 x 236.7 mm)

Weight

9400 g / 7900 g / 6000 g / 3300 g

Bluetooth Version

NA

Wired LAN (RJ-45)

Yes

Wireless LAN

Dell Wireless 1530 half miniPCIe WLAN card (802.11n), Dell Wireless 1530 PCIe WLAN card (802.11n)

Brand

Dell

Model

Optiplex 7010

Base Frequency

2.50 GHz / 3.40 GHz / 3.40 GHz

Maximum Frequency

NA / NA / 3.90 GHz

Cache

2 MB / 3 MB / 8 MB

Number of Cores

2 / 2 / 4

Processor Name

Intel Celeron G540 / Intel Core i3-3240 / Intel Core i7-3770

Standard Memory Size

2 GB

Memory Type

1600 MHz DDR3

Number of Slots

Ultra Small Factor model: 2 / All other models: 4

Max Supported

Ultra Small Factor model: 4 GB / All other models: 8 GB

Drive Type

2.5" SATA 7200 RPM HDD / 3.5" SATA 7200 HDD

Max Size

500 GB / 1 TB

SD Card Options

Media Card reader (Only for Mini Tower and Desktop)

HDMI Ports

None

RJ-45 (Ethernet) Ports

1

Thunderbolt

None

USB Ports

Ultra Small Factor model: 2 USB 2.0 & 4 USB 3.0, Small Form Factor Model: 6 USB 2.0, & 4 USB 3.0 / All other models: 8 USB 2.0 & 4 USB 3.0

Operating System (OS)

Up to Windows 7 Ultimate SPI (32 and 64 bit)

Audio/Sound

Dell AX210 USB Stereo speakers, Dell AX510/AX510PA Flat Panel Soundbar Speakers, Realtek ALC269Q High Definition Audio Codec

Optical Drive

Mini Tower and Desktop Model (DVD+/-RW2 SATA / DVD-ROM3 SATA), Small Form Factor and Ultra Small Form Factor (needs slim-line optical drive)

Graphics Card Name

Integrated HD Graphics / Intel HD Graphics 2500 / Intel HD Graphics 4000 / AMD RADEON HD 7570 / AMD RADEON HD 7470

GPU Interface

Integrated / Integrated / Integrated/ Dedicated / Dedicated

Dedicated VRAM

None / None / None/ 1 GB / 1 GB

Base GPU Frequency

850 MHz / 650 MHz / 650 MHz /650 MHz / 750 MHz

Boost GPU Frequency

1000 MHz / 1050 MHz / 1150 MHz / NA / NA
