For an ideal p–n junction, forward current follows the Shockley relationship ID = IS[exp(VD/(nVT)) − 1]. Increasing junction voltage therefore produces a multiplicative increase in current, while voltage rises only logarithmically with current. Real terminal measurements follow this law only over a useful middle range; series resistance, recombination, heating and device construction alter the curve outside it.
What forward conduction means
A p–n diode is forward-biased when its p-side is at a higher electric potential than its n-side. The applied voltage lowers the depletion-region barrier, allowing carriers to be injected across the junction. “Forward-conducting” does not mean that a diode waits for a universal threshold such as 0.7 V. In the ideal equation, some current exists at every finite forward voltage; a circuit designer chooses when that current is significant.
TI describes about 0.6 V as a typical room-temperature silicon forward drop, but the value depends on current, temperature and ideality factor (TI reference guide).
The Shockley diode equation
ID = IS[eVD/(nVT) − 1]
- ID: diode current.
- VD: voltage across the junction.
- IS: saturation-current model parameter.
- n: emission or ideality factor.
- VT = kT/q: thermal voltage, with T in kelvins.
At 300.15 K (about 27 °C), VT is approximately 25.865 mV. TI gives the same equation and its logarithmic form for forward-current analysis and parameter extraction (application report).
