Dell Optiplex 9020
- Processor: Up to 4-core Intel Core i7-4790, 3.60 GHz, 8 MB Cache
- Memory: Micro and Ultra-small form factor: Up to 16 GB 1600 MHz DDR3. 2 DIMM slots; All other models: Up to 32 GB 1600 MHz DDR3, 4 DIMM slots
- Storage: Up to 2 TB SATA 7200 RPM HDD, or up to 2 TB SATA 5400 RPM HDD, or up to 256 GB SSD
- Graphics: Intel HD Graphics 4600, or 1 GB AMD Radeon HD8490, or 1 GB AMD Radeon HD8570, or 1 GB NVIDIA Geforce GTX 645
| Release Date | 2013 |
|---|---|
| Dimensions (W x D x H) | Mini-Tower (175 x 417 x 360 mm) / Small Form Factor (92.6 x 312 x 290 mm) / Ultra-small form factor (65 x 240 x 236.7 mm) / Micro (36 x 176 x 182 mm) |
| Weight | 7700 g / 5000 g / 6000 g / 3500 g / 1280 g |
| Bluetooth Version | NA |
| Wired LAN (RJ-45) | Yes |
| Wireless LAN | Broadcom NetXtreme 10/100/1000 PCIe Gigabit Networking Card (Optional), Dell Wireless 1540 miniPCIe WLAN card (802.11a/b/g/n) (Optonal), Dell Wireless 1540 PCIe WLAN card (802.11a/b/g/n) (Optional), Dell Wireless 7260 M.2 WLAN card (802.11ac) (Optional), Intel i217 LM Gigabit1 Ethernet LAN 10/100/1000 |
| Brand | Dell |
| Model | Optiplex 9020 |
| Base Frequency | 3.60 GHz |
| Maximum Frequency | 4.0 GHz |
| Cache | 8 MB |
| Number of Cores | 4 |
| Processor Name | Intel Core i7-4790 |
| Standard Memory Size | 2 GB |
| Memory Type | 1600 MHz DDR3 |
| Number of Slots | 2 DIMM slots / 2 So-DIMM slots / 4 DIMM slots |
| Max Supported | 32 GB |
| Drive Type | SATA 7200 RPM HDD / SATA 5400 RPM HDD / SSD |
| Max Size | 1 TB / 2 TB / 256 GB |
| SD Card Options | Mini tower: Dell 19-in-1 Media Card Reader; all other models: None |
| HDMI Ports | HDMI (Only for Micro model) (Optional) |
| RJ-45 (Ethernet) Ports | 1 |
| Thunderbolt | None |
| USB Ports | Mini Tower: 8 USB 2.0, 4 USB 3.0 / Small Form Factor: 6 USB 2.0, 4 USB 3.0 / Ultra-Small Form Factor: 2 USB 2.0, 4 USB 3.0 / Micro: 6 USB 3.0 |
| Operating System (OS) | Windows 7 Pro (32-bits & 64-bits) / Windows 8.1 Pro (64-bits) / Windows 8.1 (64-bits) / Ubuntu 12.04 (64-bit) |
| Audio/Sound | Line in for microphone / stereo, Line out for headphones / speakers, Realtek ALC3220 High Definition Audio Codec, Realtek ALC3234 High Definition Audio Codec |
| Optical Drive | DVD-ROM, DVD+/-RW |
| Graphics Card Name | Intel HD Graphics 4600 / AMD Radeon HD8490 / AMD Radeon HD8570 / NVIDIA Geforce GTX 645 |
| GPU Interface | Integrated / Dedicated / Dedicated / Dedicated |
| Dedicated VRAM | None / 1 GB DDR3 / 1 GB DDR3 / 1 GB GDDR5 |
| Base GPU Frequency | 350 MHz / 875 MHz / 650 MHz / 823 MHz |
| Boost GPU Frequency | 1200 MHz / NA / NA / NA |
