Dell Optiplex 755
- Processor: Up to 2-core Intel Celeron 440, 2.0 GHz, 512 KB Cache, or up to 2-core Intel Core 2 Duo E4600, 2.40 GHz, 2 MB L2 Cache or up to 2-core Intel Core 2 Duo E6850, 3.0 GHz, 4 MB Cache, or up to 4-core Intel Core 2 Q6700, 2.66 GHz, 8 MB L2 Cache
- Memory: Ultra Small Factor model: Up to 4 GB 800 MHz / 667 MHz Non-ECC SDRAM DDR2, 2 DIMM Slots; All other models: Up to 8 GB 800 MHz / 667 MHz Non-ECC SDRAM DDR2, 4 DIMM Slots
- Storage: Up to 500 GB SATA 7200 RPM HDD
- Graphics: Ultra Small Factor model: Integrated Intel Graphics Media Accelerator 3000; All other models: Integrated Intel Graphics Media Accelerator 3000, or 128 MB ATI Radeon X1300, or 256 MB ATI Radeon HD 2400 PRO, or 256 MB ATI Radeon HD 2400 XT
| Release Date | 2008 |
|---|---|
| Dimensions (W x D x H) | Mini-Tower (185 x 439 x 414 mm) / Desktop (399 x 353 x 114 mm) / Small Form Factor (314 x 340 x 92.6 mm) / Ultra Small Form Factor (89 x 253 x 264 mm) |
| Weight | 11700 g / 8260 g / 6800 g / 4540 g |
| Bluetooth Version | NA |
| Wired LAN (RJ-45) | Yes |
| Wireless LAN | Broadcom NetXtreme 10/100/1000 PCIe Gigabit Networking Card, Intel 82566DM Gigabit LAN 10/100/1000 |
| Brand | Dell |
| Model | Optiplex 755 |
| Base Frequency | 2.0 GHz / 2.40 GHz / 3.0 GHz / 2.66 GHz |
| Maximum Frequency | 2.0 GHz / 2.40 GHz / 3.0 GHz / 2.66 GHz |
| Cache | 512 KB / 2 MB / 4 MB / 8 MB |
| Number of Cores | 2 / 2 / 2 / 4 |
| Processor Name | Intel Celeron 440 / Intel Core 2 Duo E4600 / Intel Core 2 Duo E6850 / Intel Core 2 Q6700 |
| Standard Memory Size | 1 GB |
| Memory Type | 800 MHz / 667 MHz Non-ECC SDRAM DDR2 |
| Number of Slots | Ultra Small Factor model: 2 / All other models: 4 |
| Max Supported | Ultra Small Factor model: 4 GB / All other models: 8 GB |
| Drive Type | SATA 7200 RPM HDD |
| Max Size | 500 GB |
| SD Card Options | None, Ultra small form factor model: None / All other models: Dell 19-in-1 Media Card Reader |
| HDMI Ports | None |
| RJ-45 (Ethernet) Ports | 1 |
| Thunderbolt | None |
| USB Ports | Ultra Small Factor model: 7 USB 2.0 ports (2 front & 5 back) / All other models: 10 USB 2.0 ports (2 front, 6 back & 2 internal) |
| Operating System (OS) | Windows Vista / Windows XP |
| Audio/Sound | ADI 1984 High Definition Audio, Dell A225 Speakers / Dell A525 Speakers (Optional), Dell AS501 Flat Panel Speakers (Sound Bar) / Dell AS501PA Flat Panel Speakers (Sound Bar) (Optional), Internal Chassis Speaker (Optional) |
| Optical Drive | Mini Tower and Desktop models (48X CD-ROM SATA, or 48x/32x/48x/16x Combo Drive CD-RW, 16x SATA DVD-ROM SATA, or 16x DVD+/-RW SATA), Small Form Fator and Ultra Small Form Fator (24x EIDE CD-ROM Drive, or 24x/24x/24x EIDE Combo Drive CD-RW or 8x EIDE DVD-ROM, 8x EIDE DVD+/-RW) |
| Graphics Card Name | Intel Graphics Media Accelerator 3000 / ATI Radeon X1300 / ATI Radeon HD 2400 PRO / ATI Radeon HD 2400 XT |
| GPU Interface | Integrated / PCI Express x16 / PCI Express x16 / PCI Express x16 |
| Dedicated VRAM | None / 128 MB / 256 MB DDR2 / 256 MB DDR2 |
| Base GPU Frequency | 350 MHz / 450 MHz / 525 MHz / 650 MHz |
| Boost GPU Frequency | NA / NA / NA / NA |
